RA135N25MF SPD for use in power supply and video monitoring systems

Category:

Description：Compact 3 in 1 SPD for use in power supply and video monitoring systems, and installation at the boundaries from
LPZ 0B -2 and higher.

Features：

● High discharge capacity

● Reliable thermo disconnect device equipment

● Capable of protecting terminal equipment

● Visual and remote status indication

● Small size

● Easy installation

Description

Part Number RA135N25MF
Max. continuous operating d.c. voltage (Uc) 135V
Rate load current(45℃) (IL) 20A
C2 nominal discharge current (8/20 µs) per line (In) 20KA
Voltage protection level for line-line in C2 (Up) 650V
Voltage protection level for line-line at 1kV/ µs C3 (Up) 800V
Frequency scope for line-line 0-3.2GHz
Insertion loss 0.15dB(0-2.5GHz),0.2dB(2.5-3.2GHz)
Surge impedance 50Ω
Approval CE
